Применение

Автомобилестроение


Automotive

In the automobile industry increasing efforts are being made to develop alternative production methods. Mathis AG supplies various processes which are already in use in the automobile industry. Do you have an idea but have not found a partner for its implementation? We enjoy new challenges and work with you to develop ....

Защитные и декоративные плёнки для оклейки автомобилей

Plastic foils are coated and lacquered in the color of vehicle, coated with a protective layer and pressed into the required form. The back of the component is then sprayed with an inexpensive plastic and can then be mounted on the vehicle.

Оборудование Mathis для автомобильной промышленности




DWE. Устройство для валкового нанесения покрытий

DWE. Устройство для валкового нанесения покрытий

The roller application device type «DWE» is especially suitable for controlled application by means of a screen or stippling roller with a doctor blade. By using engraved rollers, precisely controlled application of plain colors, lacquers, glue and adhesives, primers, coatings etc. is achieved. Application of solvent-containing, aqueous and 100 % systems as well ....





  Инфракрасная сушка IR-K

Инфракрасная сушка IR-K

IR dryer into which the material holders of the previously mentioned dryers and coaters can be placed. Infinitely variable heating from above, below or both sides. Short wave IR radiators.





LABCOATER with Coating Device

Лабораторная установка Labcoater LTE-S для нанесения и сушки покрытий

LABCOATER type «LTE-S», the optimum combination of dryer and laboratory coating table. Various kinds of material samples are coated and heat treated in the same run. The coating is applied either by a floating, roller or rubber blanket knife. Multiple coatings which do not require re-loading are also possible.





Coating Device

Laboratory coating unit type «SV»

The laboratory coating device type «SV» is used to coat single material samples. Coating is performed with a floating, roller or rubber blanket knife.





Laboratory Hot Air Oven

Laboratory hot air oven type «LTH»

This hot-air oven can be used for drying, hardening and baking primers, paints, lacquers or similar surface coatings. The sample material such as steel sheets, aluminum etc. can be coated on our Reverse Roll Coater RRC-BW with the «coil coating method». After coating the sample is placed onto a holder and transported into the dryer for subsequent heat treatment.





Reverse Roll Coater

Reverse roll coater type «BA-RRC»

Multiple roller applicator for the application of primers, lacquers, solvent-containing, aqueous and 100% systems, UV lacquers as well as pretreating agents onto aluminum, steel sheets and other materials. The plant conditions can be reproduced on a small sample size as various parameters such as roller speed and roller distance can be set precisely.





Paste Evacuating Device

Paste evacuating device type «LPE»

This table model can be used when air and bubble free pastes, lacquers etc are required.





Continuous coating systems

Continuous coating systems type «KTF-S»

Continuous doctor knife coating with subsequent drying are the basic functions of the «KTF-S». The continuous coating system type «KTF-S» is used where the required sample length makes economic use of a large machine impossible.





Coil coating system for coating and drying steel and aluminum coils

Coil coating system type «BA 15706»

Coil coating system for coating and drying steel and aluminum coils. The application material, in this case lacquers of different colors, is applied to one or both sides of an aluminum coil with the «reverse roll coating» process. In two-shift operation up to 38,000 meters of aluminum coil are coated daily.





Production of Battery Components

Production of battery components, type «BA 16006»

The application material is applied to a metal or plastic foil or paper in a reverse roll coating process or as a doctor knife coating. The coated web feed runs through various drying stages and is subsequently wound up.





Foil coating Range

Foil coating Range for the painting industry type BA 20712

A coloured base coat and clear coat are applied to foil and pre-dried. This coating is only around one millimeter thick. Covered by a transparent protective coating, it can be cut to size and applied in large or small-scale production runs at almost any location. Here, the foil is deep-drawn into the final shape, cured with UV light and back-foamed to the completed c ....





Crockmeter for friction resistance

Crockmeter for friction resistance «CRO-B»

Crockmeter type «CRO-B», to determine the abrasion resistance of dyed and printed textiles. Tests are carried out on dry or wet textiles in accordance with internationally recognized standards.
(BS 1006D02, ISO 105-X12/D02 ATTCC 8-2001).
